| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| ELECTRICAL DATA | V-Ph-Hz | 115V / 208/230V / 1Ph / 60Hz |
| NOMINAL COOLING CAPACITY | kBTU/h | 54 |
| AIRFLOW VOLUME (RANGE) | CFM | 1,800 |
| EXTERNAL STATIC PRESSURE | Pa | 200 |
| INPUT POWER | + | 6,750 |
| INPUT CURRENT | A | 31 |
| CIRCUIT BREAKER CAPACITY | A | 15 |
| SOUND PRESSURE LEVEL | dB(A) | 59 |
| EVAP HEAT EXCHANGER CONFORMATION | - - - | Copper tubes with aluminum fins and golden fin coating |
| REFRIGERANT | - - - | R32 |
| PIPE DIAMETER, LIQUID LINE | inch | 3/8 |
| PIPE DIAMETER, GAS LINE | inch | 7/8 |
| DRAIN PIPE (OUTER DIAMETER X THICKNESS) | mm | φ24 |
| CONTROLLER (Model) | - | Wired Controller Included |
| AIR DISCHARGE DIMENSIONS (L x W) | inch | 22-3/4 x 10-5/16 |
| AIR RETURN DIMENSIONS (L x W) | inch | 16 x 23-1/4 |
| PRODUCT DIMENSIONS (W x H x D) | inch | 24-1/2 x 56 x 21 |
| PACKAGING DIMENSIONS (W x H x D) | inch | 29-5/16 x 62-9/16 x 26-1/4 |
| NET WEIGHT | lbs | 158.4 |
| GROSS WEIGHT | lbs | 196.0 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| ELECTRICAL DATA | V-Ph-Hz | 115V / 208/230V / 1Ph / 60Hz |
| NOMINAL COOLING CAPACITY | kBTU/h | 54 |
| AIRFLOW VOLUME (RANGE) | CFM | 1,800 |
| EXTERNAL STATIC PRESSURE | Pa | 200 |
| INPUT POWER | + | 6,750 |
| INPUT CURRENT | A | 31 |
| CIRCUIT BREAKER CAPACITY | A | 15 |
| SOUND PRESSURE LEVEL | dB(A) | 59 |
| EVAP HEAT EXCHANGER CONFORMATION | - - - | Copper tubes with aluminum fins and golden fin coating |
| REFRIGERANT | - - - | R32 |
| PIPE DIAMETER, LIQUID LINE | inch | 3/8 |
| PIPE DIAMETER, GAS LINE | inch | 7/8 |
| DRAIN PIPE (OUTER DIAMETER X THICKNESS) | mm | φ24 |
| CONTROLLER (Model) | - | Wired Controller Included |
| AIR DISCHARGE DIMENSIONS (L x W) | inch | 22-3/4 x 10-5/16 |
| AIR RETURN DIMENSIONS (L x W) | inch | 16 x 23-1/4 |
| PRODUCT DIMENSIONS (W x H x D) | inch | 24-1/2 x 56 x 21 |
| PACKAGING DIMENSIONS (W x H x D) | inch | 29-5/16 x 62-9/16 x 26-1/4 |
| NET WEIGHT | lbs | 158.4 |
| GROSS WEIGHT | lbs | 196.0 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| RATED VOLTAGE | V~ | 208/230 |
| SEER | SEER | 23 |
| COOLING CAPACITY | BTU/h | 38,000 |
| HEATING CAPACITY | BTU/h | 42,000 |
| COOLING POWER INPUT | W | 3,400 |
| HEATING POWER INPUT | W | 3,600 |
| COOLING CURRENT | A | 14.8 |
| HEATING CURRENT | A | 15.7 |
| REFRIGERANT | R | R32 |
| REFRIGERANT CHARGE | oz | 84.7 |
| ODU SOUND POWER LEVEL | dB | 67 |
| DIMENSION ODU (WxDxH) | in | 42.64 × 19.45 × 33.78 |
| ODU NET WEIGHT | lb | 151.0 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| RATED VOLTAGE | V~ | 208/230 |
| SEER | SEER | 24 |
| COOLING CAPACITY | BTU/h | 42,000 |
| HEATING CAPACITY | BTU/h | 42,000 |
| COOLING POWER INPUT | W | 3,760 |
| HEATING POWER INPUT | W | 3,330 |
| COOLING CURRENT | A | 16.3 |
| HEATING CURRENT | A | 14.5 |
| REFRIGERANT | R | R32 |
| REFRIGERANT CHARGE | oz | 84.7 |
| ODU SOUND POWER LEVEL | dB | 67 |
| DIMENSION ODU (WxDxH) | in | 42.64 × 19.45 × 33.78 |
| ODU NET WEIGHT | lb | 154.3 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| Model | － | UADH48-DD3D1 |
| Rated voltage | V | 208/230 |
| Cooling power input | kW | 0.31 |
| Heating power input | kW | 0.31 |
| Cooling current | A | 2.15 |
| Heating current | A | 2.15 |
| Refrigerant | R | R410A |
| IDU Sound power level | dB (A) | 60 |
| Dimension IDU(WxDxH) | in | 24 3/4 x 21 1/4 x 57 |
| IDU Net weight | lb | 202 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| Model | － | UADH60-DD3D1 |
| Rated voltage | V | 208/230 |
| Cooling power input | kW | 0.42 |
| Heating power input | kW | 0.42 |
| Cooling current | A | 0.42 |
| Heating current | A | 0.42 |
| Refrigerant | R | R410A |
| IDU Sound power level | dB (A) | 61 |
| Dimension IDU(WxDxH) | in | 24 3/4 x 21 1/4 x 57 |
| IDU Net weight | lb | 203 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| POWER SUPPLY | V-Ph-Hz | 208/230-1-60 |
| RATED COOLING CAPACITY | kBTU/h | 36 |
| RATED HEATING CAPACITY | kBTU/h | 36 |
| EFFICIENCY RATING | SEER2 | 18 |
| COMPRESSOR POWER INPUT | W | 2050 |
| RATED LOAD AMPS (RLA) | A | 8.2 |
| MAX. OVERCURRENT PROTECTION (MOP) | A | 40 |
| SOUND PRESSURE LEVEL | dB(A) | 68 |
| CONDENSER COIL ROWS | － | 2 |
| COMPRESSOR TYPE / BRAND | － | Variable Rotary / GMCC |
| REFRIGERANT TYPE | － | R32 |
| FACTORY REFRIGERANT CHARGE | oz | 88.2 |
| PRE-CHARGED STANDARD LINE LENGTH | ft | 25 |
| ADDITIONAL CHARGE RATE | oz/ft | 0.38 |
| LIQUID LINE SIZE | inch | 3/8" |
| GAS/SUCTION LINE SIZE | inch | 3/4" |
| MAX. PIPE ELEVATION (IDU-ODU) | ft | 49 |
| MAX. TOTAL LINESET LENGTH | ft | 98 |
| AMBIENT OPERATING TEMP. RANGE (COOLING) | °F | 5 ~ 125 °F |
| AMBIENT OPERATING TEMP. RANGE (HEATING) | °F | -4 ~ 80 °F |
| UNIT DIMENSIONS (W x H x D) | inch | 29-1/8 × 24-15/16 × 29-1/8 |
| PACKING DIMENSIONS (W x H x D) | inch | 30-1/4 x 31-1/4 x 30-1/4 |
| NET WEIGHT | lbs | 141.1 |
| GROSS WEIGHT | lbs | 169.8 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| POWER SUPPLY | V-Ph-Hz | 208/230-1-60 |
| RATED COOLING CAPACITY | kBTU/h | 54 |
| RATED HEATING CAPACITY | kBTU/h | 54 |
| EFFICIENCY RATING | SEER2 | 17 |
| COMPRESSOR POWER INPUT | W | 3540 |
| RATED LOAD AMPS (RLA) | A | 12.2 |
| MAX. OVERCURRENT PROTECTION (MOP) | A | 60 |
| SOUND PRESSURE LEVEL | dB(A) | 69 |
| CONDENSER COIL ROWS | － | 2 |
| COMPRESSOR TYPE / BRAND | － | Variable Rotary / HIGHLY |
| REFRIGERANT TYPE | － | R32 |
| FACTORY REFRIGERANT CHARGE | oz | 123.5++ |
| PRE-CHARGED STANDARD LINE LENGTH | ft | 25 |
| ADDITIONAL CHARGE RATE | oz/ft | 0.38 |
| LIQUID LINE SIZE | inch | 3/8" |
| GAS/SUCTION LINE SIZE | inch | 7/8" |
| MAX. PIPE ELEVATION (IDU-ODU) | ft | 82 |
| MAX. TOTAL LINESET LENGTH | ft | 164 |
| AMBIENT OPERATING TEMP. RANGE (COOLING) | °F | 5 ~ 125 °F |
| AMBIENT OPERATING TEMP. RANGE (HEATING) | °F | -4 ~ 80 °F |
| UNIT DIMENSIONS (W x H x D) | inch | 29-1/8 x 33-3/16 x 29-1/8 |
| PACKING DIMENSIONS (W x H x D) | inch | 30-1/4 x 39-1/2 x 30-1/4 |
| NET WEIGHT | lbs | 183.0 |
| GROSS WEIGHT | lbs | 216.1 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| RATED VOLTAGE | V~ | 208/230 |
| SEER | SEER | 23 |
| COOLING CAPACITY | BTU/h | 38,000 |
| HEATING CAPACITY | BTU/h | 42,000 |
| COOLING POWER INPUT | W | 3,400 |
| HEATING POWER INPUT | W | 3,600 |
| COOLING CURRENT | A | 14.8 |
| HEATING CURRENT | A | 15.7 |
| REFRIGERANT | R | R32 |
| REFRIGERANT CHARGE | oz | 84.7 |
| ODU SOUND POWER LEVEL | dB | 67 |
| DIMENSION ODU (WxDxH) | in | 42.64 × 19.45 × 33.78 |
| ODU NET WEIGHT | lb | 151.0 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| RATED VOLTAGE | V~ | 208/230 |
| SEER | SEER | 24 |
| COOLING CAPACITY | BTU/h | 42,000 |
| HEATING CAPACITY | BTU/h | 42,000 |
| COOLING POWER INPUT | W | 3,760 |
| HEATING POWER INPUT | W | 3,330 |
| COOLING CURRENT | A | 16.3 |
| HEATING CURRENT | A | 14.5 |
| REFRIGERANT | R | R32 |
| REFRIGERANT CHARGE | oz | 84.7 |
| ODU SOUND POWER LEVEL | dB | 67 |
| DIMENSION ODU (WxDxH) | in | 42.64 × 19.45 × 33.78 |
| ODU NET WEIGHT | lb | 154.3 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| Model | － | UADH48-DD3D1 |
| Rated voltage | V | 208/230 |
| Cooling power input | kW | 0.31 |
| Heating power input | kW | 0.31 |
| Cooling current | A | 2.15 |
| Heating current | A | 2.15 |
| Refrigerant | R | R410A |
| IDU Sound power level | dB (A) | 60 |
| Dimension IDU(WxDxH) | in | 24 3/4 x 21 1/4 x 57 |
| IDU Net weight | lb | 202 |
| DESCRIPTION | UNIT | PARAMETER |
|---|---|---|
| Model | － | UADH60-DD3D1 |
| Rated voltage | V | 208/230 |
| Cooling power input | kW | 0.42 |
| Heating power input | kW | 0.42 |
| Cooling current | A | 0.42 |
| Heating current | A | 0.42 |
| Refrigerant | R | R410A |
| IDU Sound power level | dB (A) | 61 |
| Dimension IDU(WxDxH) | in | 24 3/4 x 21 1/4 x 57 |
| IDU Net weight | lb | 203 |
