Maxum Pro Series

DESCRIPTION	UNIT	PARAMETER
RATED VOLTAGE	V~	208/230
SEER	SEER2	25
COOLING INPUT POWER	W	1,540
HEATING INPUT POWER	W	1,320
COOLING INPUT CURRENT	A	6.7
HEATING INPUT CURRENT	A	5.7
MAX. FUSE SIZE	A	20.0
CIRCUIT BREAKER	A	20.0
WHIP SIZE	AWG	14.0
NOISE LEVEL	dB(A)	56.0
CONFIRMATION OF THE COND. HEAT EXCHANGER	---	Copper tubes with Gold Fin coated aluminum fins
COMPRESSOR TYPE	---	Single-Rotatory
REFRIGERANT	---	R32
REFRIGERANT CHARGE	ozs	42.3
PIPE DIAMETER, LIQUID LINE	in	1/4
PIPE DIAMETER, GAS LINE	in	3/8
MAXIMUM CONNECTION ELEVATION(IDU-ODU)	ft	33.0
MAXIMUM PIPE CONNECTION LENGTH	ft	49.0
AMBIENT TEMP. RANGE, COOLING OPERATION	°F	5~131/-13~75
ODU DIMENSIONS (A x B x C)	in	33.54 × 13.74 × 23.70
ODU PACKAGING DIMENSIONS (A x B x C)	in	37.28 x 15.04 x 24.72
NET WEIGHT ODU	lbs	72.8
GROSS WEIGHT ODU	lbs	160.5

DESCRIPTION	UNIT	PARAMETER
RATED VOLTAGE	V~	208/230
SEER	SEER2	22
COOLING INPUT POWER	W	2,500
HEATING INPUT POWER	W	2,100
COOLING INPUT CURRENT	A	10.9
HEATING INPUT CURRENT	A	9.1
MAX. FUSE SIZE	A	25.0
CIRCUIT BREAKER	A	25.0
WHIP SIZE	AWG	14.0
NOISE LEVEL	dB(A)	61.0
CONFIRMATION OF THE COND. HEAT EXCHANGER	---	Copper tubes with Gold Fin coated aluminum fins
COMPRESSOR TYPE	---	Dual-Rotary
REFRIGERANT	---	R32
REFRIGERANT CHARGE	ozs	60.0
PIPE DIAMETER, LIQUID LINE	in	1/4
PIPE DIAMETER, GAS LINE	in	3/8
MAXIMUM CONNECTION ELEVATION(IDU-ODU)	ft	33.0
MAXIMUM PIPE CONNECTION LENGTH	ft	49.0
AMBIENT TEMP. RANGE, COOLING OPERATION	°F	5~131/-13~75
ODU DIMENSIONS (A x B x C)	in	35.94 x 14.76 x 26.34
ODU PACKAGING DIMENSIONS (A x B x C)	in	39.96 x 16.73 x 28.82
NET WEIGHT ODU	lbs	97.0
GROSS WEIGHT ODU	lbs	213.8

DESCRIPTION	UNIT	PARAMETER
RATED VOLTAGE	V~	208/230
SEER	SEER2	23
COOLING INPUT POWER	W	3,400
HEATING INPUT POWER	W	3,600
COOLING INPUT CURRENT	A	14.8
HEATING INPUT CURRENT	A	15.7
MAX. FUSE SIZE	A	35.0
CIRCUIT BREAKER	A	35.0
WHIP SIZE	AWG	12.0
NOISE LEVEL	dB(A)	67.0
CONFIRMATION OF THE COND. HEAT EXCHANGER	---	Copper tubes with Gold Fin coated aluminum fins
COMPRESSOR TYPE	---	Dual-Rotary
REFRIGERANT	---	R32
REFRIGERANT CHARGE	ozs	84.7
PIPE DIAMETER, LIQUID LINE	in	1/4
PIPE DIAMETER, GAS LINE	in	3/8
MAXIMUM CONNECTION ELEVATION(IDU-ODU)	ft	33.0
MAXIMUM PIPE CONNECTION LENGTH	ft	49.0
AMBIENT TEMP. RANGE, COOLING OPERATION	°F	5~131/-13~75
ODU DIMENSIONS (A x B x C)	in	42.64 x 19.45 x 33.78
ODU PACKAGING DIMENSIONS (A x B x C)	in	48.43 x 20.87 x 36.42
NET WEIGHT ODU	lbs	151.0
GROSS WEIGHT ODU	lbs	332.9

DESCRIPTION	UNIT	PARAMETER
RATED VOLTAGE	V~	208/230
SEER	SEER2	24
COOLING INPUT POWER	W	3,760
HEATING INPUT POWER	W	3,330
COOLING INPUT CURRENT	A	16.3
HEATING INPUT CURRENT	A	14.5
MAX. FUSE SIZE	A	45.0
CIRCUIT BREAKER	A	45.0
WHIP SIZE	AWG	12.0
NOISE LEVEL	dB(A)	67.0
CONFIRMATION OF THE COND. HEAT EXCHANGER	---	Copper tubes with Gold Fin coated aluminum fins
COMPRESSOR TYPE	---	Dual-Rotary
REFRIGERANT	---	R32
REFRIGERANT CHARGE	ozs	84.7
PIPE DIAMETER, LIQUID LINE	in	1/4
PIPE DIAMETER, GAS LINE	in	3/8
MAXIMUM CONNECTION ELEVATION(IDU-ODU)	ft	33.0
MAXIMUM PIPE CONNECTION LENGTH	ft	49.0
AMBIENT TEMP. RANGE, COOLING OPERATION	°F	5~131/-13~75
ODU DIMENSIONS (A x B x C)	in	42.64 x 19.45 x 33.78
ODU PACKAGING DIMENSIONS (A x B x C)	in	48.43 x 20.87 x 36.42
NET WEIGHT ODU	lbs	154.3
GROSS WEIGHT ODU	lbs	340.2
